Performance Series Nozzles
Your favourite Toro sprinklers just got even better. Whether choosing new Infinity or Flex sprinklers or updating your existing ones, there’s now a choice of nozzles that bring an evolutionary leap in precise water delivery. Loaded into the rotors, they outperform industry standard nozzles for the ultimate in golf course irrigation efficiency. For elite level distribution uniformity and super efficient and effective water coverage, choose Toro nozzles.
The Performance Series Nozzles for INFINITY® and FLEX800™ sprinklers take precision irrigation to a new level.
Toro Infinity and Flex 800
sprinkler nozzle choice
NOZZLE SET 30 (PART 102-2208)
Infinity & Flex 35: Radius 13.1-14.3m, flow 31.0-50.7 lpm
Infinity & Flex 35-6: Radius 12.8-14.6m, flow 28.8-38.2 lpm
NOZZLE SET 31 (PART 102-0725)
Infinity & Flex 34: Radius 16.5-18.6m, flow 58.7-84.0 lpm
Infinity & Flex 35: Radius 15.8-17.7m, flow 52.2-74.2 lpm
Infinity & Flex 35-6: Radius 16.2-18.6m, flow 52.6-73.8 lpm
NOZZLE SET 32 (PART 102-0726)
Infinity & Flex 34: Radius 17.7-21.3m, flow 70.0-100.3 lpm
Infinity & Flex 35: Radius 17.4-20.4m, flow 67.8-95.4 lpm
Infinity & Flex 35-6: Radius 17.7-20.7m, flow 73.4-103.3 lpm
NOZZLE SET 33 (PART 102-0727)
Infinity & Flex 34: Radius 19.8-23.2m, flow 96.0-121.1 lpm
Infinity & Flex 35: Radius 19.8-21.3m, flow 85.4-105.2 lpm
Infinity & Flex 35-6: Radius 19.8-22.3m, flow 92.0-113.6 lpm
NOZZLE SET 34 (PART 102-7002)
Infinity & Flex 34: Radius 21.3-24.1m, flow 109.3-136.3 lpm
Infinity & Flex 35: Radius 21.3-21.9m, flow 97.1-120.0 lpm
Infinity & Flex 35-6: Radius 21.3-23.2m, flow 99.3-121.1 lpm
NOZZLE SET 35 (PART 102-0729)
Infinity & Flex 34: Radius 22.9-26.2m, flow 141.4-174.1 lpm
Infinity & Flex 35: Radius 22.9-25.3m, flow 129.4-160.9 lpm
Infinity & Flex 35-6: Radius 22.9-25.6m, flow 131.0-163.2 lpm
NOZZLE SET 36 (PART 102-0730)
Infinity & Flex 34: Radius 24.4-26.5m, flow 177.1-197.2 lpm
Infinity & Flex 35: Radius 24.4-25.6m, flow 150.3-168.5 lpm
Infinity & Flex 35-6: Radius 24.4-25.9m, flow 157.2-176.0 lpm
NOZZLE SET 37 (PART 102-4261)
Infinity & Flex 34: Radius 25.9-27.1m, flow 198.1-221.4 lpm
Infinity & Flex 35: Radius 25.9-26.2m, flow 160.3-179.0 lpm
Infinity & Flex 35-6: Radius 25.9-27.4m, flow 165.8-186.6 lpm
NOZZLE SET 51 (PART 102-0725)
Infinity & Flex 54: Radius 16.5-18.9m, flow: 60.2-85.9 lpm
Infinity & Flex 55: Radius 16.2-18.0m, flow: 52.6-75.0 lpm
Infinity & Flex 55-6: Radius 16.2-18.6m, flow: 54.9-76.8 lpm
NOZZLE SET 52 (PART 102-0726)
Infinity & Flex 54: Radius 18.3-21.9m, flow 71.5-102.2 lpm
Infinity & Flex 55: Radius 17.7-20.7m, flow 68.5-97.7 lpm
Infinity & Flex 55-6: Radius 17.7-21.3m, flow 75.3-106 lpm
NOZZLE SET 53 (PART 102-0727)
Infinity & Flex 54: Radius 19.8-22.9m, flow 97.7-123.0 lpm
Infinity & Flex 55: Radius 19.8-21.9m, flow 86.7-108.3 lpm
Infinity & Flex 55-6: Radius 19.8-22.6m, flow 96-116.2 lpm
NOZZLE SET 54 (PART 102-7002)
Infinity & Flex 54: Radius 21.3-23.5m, flow 111.3-138.2 lpm
Infinity & Flex 55: Radius 21.3-22.3m, flow 98.0-122.6 lpm
Infinity & Flex 55-6: Radius 21.3-23.2m, flow 101.8-128.3 lpm
NOZZLE SET 55 (PART 102-0729)
Infinity & Flex 54: Radius 22.9-25.6m, flow 154.6-192.7 lpm
Infinity & Flex 55: Radius 23.0-25.3m, flow 131.0-162.8 lpm
Infinity & Flex 55-6: Radius 22.9-25.9m, flow 133.0-166.2 lpm
NOZZLE SET 56 (PART 102-0730)
Infinity & Flex 54: Radius 24.4-26.5m, flow 179.0-200.6 lpm
Infinity & Flex 55: Radius 24.4-25.9m, flow 151.4-170.7 lpm
Infinity & Flex 55-6: Radius 24.4-26.8m, flow 153.9-174.5 lpm
NOZZLE SET 57 (PART 102-4261)
Infinity & Flex 54: Radius 25.9-27.4m, flow 200.1-223.7 lpm
Infinity & Flex 55: Radius 25.3-26.5m, flow 162.4-182.1 lpm
Infinity & Flex 55-6: Radius 25.9-27.4m, flow 163.5-188.5 lpm
NOZZLE SET 58 (PART 102-4260)
Infinity & Flex 54: Radius 25.9-28.7m, flow 219.3-247.6 lpm
Infinity & Flex 55: Radius 25.9-26.8m, flow 185.6-207.4 lpm
Infinity & Flex 55-6: Radius 26.8-27.4m, flow 192.9-213.3 lpm
NOZZLE SET 59 (PART 102-4259)
Infinity & Flex 54: Radius 29.6-31.7m, flow 229.8-255.3 lpm
Infinity & Flex 55: Radius 27.1-29.0m, flow 219.9-244.5 lpm
Infinity & Flex 55-6: Radius 29.0-30.5m, flow 227.5-251.1 lpm
-
Performance for all designs
Performance Series Nozzles provide a streamlined approach to simplify the design process and optimise water delivery.
- Industry-leading distribution uniformity
- Water delivery with superior precision
- True innovations for a meaningful choice
- Simplified design process
- Water delivery with precision
-
Unmatched performance
Designed to outperform the industry standard, Toro’s new Performance Series Nozzles, loaded into Infinity or Flex rotors, deliver water with precision and efficiency. Call or visit your distributor to find the right nozzles for you.
These new nozzles for Toro’s most popular sprinklers are an easy way to take your irrigation uniformity and precision to an elite level. They aptly demonstrate why Toro is known to be a guardian of the resource, providing efficient and effective water coverage.
Pete Newton
Commercial and Golf Irrigation Sales Representative at Reesink Hydro-Scapes
